Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 32
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shock
Suspension Fork
Fox 32 Float Rhythm 120 Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
Shimano Deore M6100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100
Cassette
Shimano CS-M6100 10-51t 12-Speed
Crank
Shimano MT511 32t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M6100
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Maxxis Ikon 2.20" FB 60 TPI Dual
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP21, -6º
Handlebar
Alloy, 31.8mm, Flat, 740mm, Sweep 9
Grips
OC Lock On
Seat
Saddle
Selle Italia Model X FecAlloy Rail 145x248mm
Seatpost
Alloy, 31.6mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.333 mm | 1.292 mm | 1.248 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 736 mm | 762 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 596 mm | 600 mm | 610 mm | 619 mm |
| Reach | 425 mm | 450 mm | 472 mm | 496 mm |
| Top Tube Length | 568 mm | 594 mm | 619 mm | 645 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 410 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1142 mm | 1169 mm | 1195 mm | 1223 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 729 mm | 743 mm | 746 mm | 743 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
