Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset X0, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Level Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMX, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SC Factory 120 Grip SL Remote-Adj Push to Lock QR15x110 Kashima
Rear Shock
Fox Float SL Factory 120mm Remote Push-lock Evol Kashima custom tune 190x45mm
Drivetrain
Rear Derailleur
SRAM X0 Eagle AXS
Shift Levers
SRAM AXS Pod
Cassette
SRAM GX-1275 Eagle 10-52t 12-Speed
Crank
SRAM X0 Eagle Dub Black 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM GX Eagle 12-Speed
Wheels
Rims
Oquo Mountain Performance MP30TEAM
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
SRAM Level Silver 2 piston Hydraulic Disc
Cockpit
Handlebar
OC Mountain Performance MP10 Carbon, Cockpit, Width 760
Seat
Saddle
Selle Italia SLR Boost Fill Titanium Rail 316 Ø7 mm
Seatpost
OC Mountain Performance DP-MP10, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.324 mm | 1.284 mm | 1.248 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 596 mm | 596 mm | 606 mm | 619 mm |
| Reach | 425 mm | 450 mm | 472 mm | 496 mm |
| Top Tube Length | 575 mm | 598 mm | 623 mm | 650 |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1138 mm | 1163 mm | 1189 mm | 1219 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 731 mm | 741 mm | 741 mm | 750 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
