Orbea OIZ M-TEAM FACTORY 2025
2025 Mountain
Estimate price |
10,818$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset Dura-Ace Di2, XTR -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Shimano XTR Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMX, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SL Factory 120, Grip SL, Remote-Adj Push to Lock, QR15x110, Kashima
Rear Shock
Fox Float SL Factory 120mm Remote Push-lock Evol Kashima custom tune 190x45mm
Drivetrain
Rear Derailleur
Shimano XTR M9250 SGS
Shift Levers
Shimano XTR M9250
Cassette
Shimano CS-M9200 10-51t 12-Speed
Crank
Shimano XTR M9200 34t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-9100
Wheels
Rims
Oquo Mountain Performance MP30LTD
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
Shimano XTR Hydraulic Disc
Cockpit
Handlebar
OC Mountain Performance MP10 Carbon, Cockpit, Width 760
Seat
Saddle
Selle Italia SLR Boost Elite Fill, Rail Ø7 mm
Seatpost
Fox Transfer SL Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.324 mm | 1.284 mm | 1.248 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 596 mm | 596 mm | 606 mm | 619 mm |
| Reach | 425 mm | 450 mm | 472 mm | 496 mm |
| Top Tube Length | 575 mm | 598 mm | 623 mm | 650 |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1138 mm | 1163 mm | 1189 mm | 1219 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 731 mm | 741 mm | 741 mm | 750 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
