Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2, Ultegra -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Dura-Ace Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
Suspension Fork
Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 R8150
Front Derailleur
Shimano Ultegra Di2 R8150
Shift Levers
Shimano R9180
Cassette
Shimano Ultegra R8100 11-30t 12-Speed
Crank
Shimano Ultegra R8100 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano M8100
Wheels
Rims
Oquo Road Performance RP57LTD
Tires
Vittoria Corsa N.Ext G2.0 Foldable 700x28c
Brakes
Brakes
Shimano R9270 Hydraulic Disc
Cockpit
Handlebar
Orbea Ordu OMX
Seat
Saddle
Fizik Transiro LD R5 size 135mm
Seatpost
Orbea Ordu OMX, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 613 mm | 613 mm | 654 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 451 mm | 486 mm | 486 mm | 536 mm |
| Reach | 641 mm | 665 mm | 665 mm | 689 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 492 mm | 527 mm | 527 mm | 527 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 59 mm | 96 mm | 96 mm | 149 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 970 mm | 1006 mm | 1006 mm | 1047 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 781 mm | 781 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
