Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
Suspension Fork
Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Drivetrain
Bottom Bracket
386EVO, 86mm, press-fit
Wheels
Rims
Orbea Thru Axle 12x100mm M12x2 P1 Lite
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
Orbea Ordu OMX
Headset
FSA 1-1/8"-1" Integrated Aluminium Cup
Seat
Seatpost
Orbea Ordu OMX, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 613 mm | 613 mm | 654 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 451 mm | 486 mm | 486 mm | 536 mm |
| Reach | 641 mm | 665 mm | 665 mm | 689 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 492 mm | 527 mm | 527 mm | 527 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 59 mm | 96 mm | 96 mm | 149 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 970 mm | 1006 mm | 1006 mm | 1047 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 781 mm | 781 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
