Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 203mm -
Fork Fox Factory Float 40
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Shimano XTR Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Rallon OMR. 442mm chainstay length. Concentric Boost 12x148 rear axle. Pure Gravity geometry. Attitude Adjust. ISCG05
Suspension Fork
Fox 40 Float Factory 203, Grip X2, 20x110, Kashima
Rear Shock
Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 225x75mm
Drivetrain
Rear Derailleur
Shimano SAINT M820 SS Shadow Plus
Shift Levers
Shimano Saint M820
Cassette
Shimano CS-M771 11-32t 10-Speed
Crank
Race Face Turbine 34t
Chain
Shimano HG95
Chain Guide
e*thirteen CL55 30-36t black
Wheels
Rims
Oquo Mountain Control MC32TEAM (29" Front / 27,5" Rear)
Tires
Maxxis Minion DHR 2.40" WT FB 60x2 TPI 3C MaxxGrip DH TR
Brakes
Brakes
Shimano XTR Hydraulic Disc
Cockpit
Stem
Race Face Atlas 35 Direct Mount
Handlebar
OC Mountain Control MC20 Alu SL, Rise20, Width 800
Seat
Saddle
Fizik Gravita Alpaca X5
Seatpost
Race Face Turbine 31.6x400mm
