Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Shimano GRX 400 Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", BB386EVO, powermeter compatible, Thru Axle 12x142mm rear, thread M12xP1, UDH dropout, LOCKR XXL service box, MMS munti mount system, fender ready.
Suspension Fork
Orbea Terra Race ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready.
Drivetrain
Rear Derailleur
Shimano GRX RX820
Front Derailleur
Shimano GRX RX820
Shift Levers
Shimano GRX RX610
Cassette
Shimano HG710 11-36t 12-Speed
Crank
Shimano GRX RX610 30x46t
Bottom Bracket
BB86/BB92, press-fit
Chain
Shimano M6100
Wheels
Rims
Oquo Road Control RC30TEAM
Tires
Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x45c
Brakes
Brakes
Shimano RX410 Hydraulic disc
Cockpit
Stem
OC Road Performance RP23, -5º
Handlebar
OC Gravel GR31, Reach 70, Drop 110
Seat
Saddle
Fizik Terra Argo X7 Aluminium Rail 150mm
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.423 mm | 1.45 mm | 1.483 mm | 1.517 mm | 1.547 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 614 mm | 624 mm | 635 mm | 643 mm | 654 mm | 663 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82.7 mm | 79.5 mm | 76.2 mm | 73 mm | 71.4 mm | 69.8 mm |
| Stack | 535 mm | 558 mm | 580 mm | 602 mm | 625 mm | 645 mm |
| Reach | 386 mm | 392 mm | 400 mm | 406 mm | 412 mm | 417 mm |
| Top Tube Length | 535 mm | 547 mm | 561 mm | 573 mm | 585 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 505 mm | 540 mm | 575 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° | 70.5 ° | 70.8 ° | 71 ° |
| Head Tube Length | 110 mm | 132.5 mm | 153.5 mm | 175 mm | 198 mm | 218 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1031 mm | 1041 mm | 1052 mm | 1061 mm | 1072 mm | 1081 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 690 mm | 717 mm | 743 mm | 772 mm | 801 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
