Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCR
-
Groupset CUES -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Orbea Internal 540Wh (Optional 250 Wh Range Extender) -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Suspension Fork
SR Suntour XCR32 LO Coil 120mm Q15x110 Boost
Drivetrain
Rear Derailleur
Shimano Cues U4000 GS Shadow
Shift Levers
Shimano Cues SL-U4000
Cassette
Shimano CS-LG300 11-46t 9-Speed
Crank
Alloy EP8 32t
Bottom Bracket
STEPS, press-fit
Chain
Shimano LG500
Chain Guide
Orbea Rise chainguide
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 29", 29c, 32H
Tires
Schwalbe Smart Sam Performance, 29x2.35, Addix, Black
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy forged, 35mm interface, -6º, ICR
Handlebar
OC Mountain Control MC31, Rise20, Width 800
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Fortune QF-3091
Seatpost
Alloy 31.6x300mm Offset 0
Motor & Battery
Motor
Shimano EP600-RS
Battery
Orbea Internal 540Wh (Optional 250 Wh Range Extender)
Charger
Orbea 2.Generation eBike Smart charger 42V/2-4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.597 mm | 1.551 mm | 1.47 mm | 1.448 mm |
| Bottom Bracket Height | 322 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 703 mm | 711 mm | 734 mm | 781 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 117 mm | 138 mm | 120 mm |
| Stack | 631 mm | 628 mm | 647 mm | 666 mm |
| Reach | 395 mm | 405 mm | 440 mm | 460 mm |
| Top Tube Length | 565 mm | 579 mm | 608 mm | 645 mm |
| Seat Tube Angle | 74.8 ° | 74.6 ° | 74.6 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 453 mm | 483 mm | 533 mm |
| Head Tube Angle | 65.5 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 115 mm | 132 mm | 153 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1143 mm | 1150 mm | 1173 mm | 1220 mm |
| Bottom Bracket Drop | 54 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 798 mm | 826 mm | 848 mm | 882 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
