Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Shimano Tourney Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Urban Speed, Aluminium 6000, Orbea Tube Shaping, Flat Mount Disc Brake, 135x9 QR, Carrier and Mudguard compatible, max 700x40C, Inner Cable routing,
Suspension Fork
Speed 400mm Alloy Flat mount
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-GS
Front Derailleur
Shimano Claris FD-R2000-F
Shift Levers
Shimano Claris SL-R2000
Cassette
Shimano HG50 11-34t 8-Speed
Crank
Orbea, Alloy, 32x48t, 8S
Chain
KMC X8
Wheels
Rims
Alloy, Tubeless, 700c, 21c, 32H
Tires
Kenda K1098 700x32 Reflective Tape
Brakes
Brakes
Shimano TX805 Mechanical Disc
Brake Levers
Shimano Claris BL-R2000
Cockpit
Stem
Alloy, 7º
Handlebar
Alloy, 31.8mm, Riser, 640mm
Seat
Saddle
Fizik Aliante R5
Seatpost
Alloy, 27.2mm, Setback 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.415 mm | 1.423 mm | 1.446 mm | 1.462 mm | 1.524 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 283 mm | 283 mm | 285 mm |
| Front Center | 596 mm | 612 mm | 626 mm | 637 mm | 648 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 67 mm | 67 mm | 67 mm | 64 mm | 60 mm |
| Stack | 535 mm | 552 mm | 571 mm | 592 mm | 625 mm |
| Reach | 378 mm | 388 mm | 395 mm | 405 mm | 410 mm |
| Top Tube Length | 521 mm | 546 mm | 559 mm | 580 mm | 601 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm | 525 mm | 555 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 109 mm | 127 mm | 150 mm | 170 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1021 mm | 1037 mm | 1052 mm | 1063 mm | 1075 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 66 mm |
| Standover Height | 738 mm | 768 mm | 800 mm | 824 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
