Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera -
Suspension Rigid -
Motor MAHLE hub-drive -
Battery Mahle 36V/6.9A 248Wh ANT+ -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Vibe Top Bar Hydro 6061 Hydroform Aluminum 2021, ICR cable routing, Forged BB, 135x9 QR, Flat Mount disc, 700x45 maximun tire, 1" 1/2 semi head set, 41x86,5 Pressfit BB, carrier and fenders compatible
Suspension Fork
Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximun tire, flat mount disc mount, Thrue Axle12x100mm, Long mudguards compatible.
Drivetrain
Rear Derailleur
Shimano Acera M3020
Shift Levers
Shimano SL-M315
Cassette
Shimano CS-HG400 11-40t 8-Speed
Crank
CR 0.1, Forged alloy, 42t, w/Chainguard
Bottom Bracket
BB86/BB92, 86mm, press-fit
Chain
KMC X8
Pedals
VP-537 Black
Wheels
Rims
Alloy, Tubeless, 700c, 21c, 32H
Tires
Kenda K1052 700x45C Reflective type+puncture protection
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy forged, -6º, ICR
Handlebar
Alloy,31.8mm, Rise 12mm, 700mm
Seat
Saddle
Selle Royal Lift 1215 URN 278x145mm
Seatpost
Alloy, 27.2mm, Setback 0, for integrated light
Motor & Battery
Motor
Mahle motor hub X35 Plus
Battery
Mahle 36V/6.9A 248Wh ANT+
Remote
Mahle iWoc TRIO
Charger
Mahle X35
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.437 mm | 1.468 mm | 1.5 mm | 1.512 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 603 mm | 624 mm | 641 mm | 667 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 80 mm | 77 mm | 70 mm | 67 mm |
| Stack | 546 mm | 580 mm | 615 mm | 650 |
| Reach | 380 mm | 395 mm | 410 mm | 430 mm |
| Top Tube Length | 507 mm | 530 mm | 547 mm | 571 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 455 mm | 490 mm | 530 mm | 575 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 109 mm | 140 mm | 175 mm | 210 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1026 mm | 1048 mm | 1065 mm | 1091 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 775 mm | 809 mm | 842 mm | 881 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
