Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 165cm
SM
162cm - 173cm
MD
170cm - 180cm
LG
177cm - 188cm
XL
185cm - 194cm
XXL
191cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Axxome GTO
Suspension Fork
Axxome III In Disc 12x100
Drivetrain
Rear Derailleur
Dura Ace 9270 Di2 disc 12v
Cassette
Dura Ace 9200 11-30 12v
Crank
Dura Ace 9200 50/34 BS
Pedals
Without pedals
Wheels
Rims
Orion C35 R Disc Evo
Tires
Power Cup 28 TR Tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
TK-278A (semi-intégrée)
Handlebar
Road Curve WCS
Seat
Saddle
SLR Boost Superflow
Seatpost
Monobloc 27,2 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.416 mm | 1.444 mm | 1.454 mm | 1.478 mm | 1.501 mm | 1.538 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 266 mm |
| Front Center | 582 mm | 588 mm | 593 mm | 602 mm | 612 mm | 625 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72 mm | 68 mm | 62 mm | 59 mm | 56 mm | 56 mm |
| Stack | 524 mm | 540 mm | 557 mm | 578 mm | 599 mm | 623 mm |
| Reach | 370 mm | 374 mm | 383 mm | 391 mm | 399 mm | 405 mm |
| Seat Tube Angle | 74 ° | 73.9 ° | 73.8 ° | 73.7 ° | 73.6 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 595 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 988 mm | 994 mm | 999 mm | 1008 mm | 1018 mm | 1032 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 162 cm | 170 cm | 177 cm | 185 cm | 191 cm |
| Rider Max Height | 165 cm | 173 cm | 180 cm | 188 cm | 194 cm | 201 cm |
