origine Graxx GTO GravelUp Edition 2025
2025 Road
Estimate price |
4,899$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 162cm
SM
159cm - 172cm
MD
169cm - 182cm
LG
179cm - 191cm
XL
188cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Graxx GTO
Suspension Fork
OGV III 12x100
Drivetrain
Rear Derailleur
GRX 820 1x12s
Cassette
SLX M7100 12s 10-51
Crank
GRX 610 12sp 40D
Pedals
Without pedals
Wheels
Rims
Vega C35 Pro Wide
Tires
Touareg Green 700x40 Tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
TK-278A (semi-intégrée)
Handlebar
Road Ergomax Comp
Seat
Saddle
SLR Boost Superflow
Seatpost
Monobloc 27,2 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.495 mm | 1.492 mm | 1.51 mm | 1.548 mm | 1.558 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 588 mm | 604 mm | 617 mm | 626 mm | 642 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 67 mm | 65 mm | 61 mm | 61 mm |
| Stack | 544 mm | 564 mm | 585 mm | 611 mm | 630 mm |
| Reach | 364 mm | 378.11 mm | 387.35 mm | 394.75 mm | 404.3 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 455 mm | 475 mm | 505 mm | 535 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.3 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 185 mm | 205 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1007 mm | 1023 mm | 1036 mm | 1045 mm | 1061 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 159 cm | 169 cm | 179 cm | 188 cm |
| Rider Max Height | 162 cm | 172 cm | 182 cm | 191 cm | 203 cm |
