Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset CUES -
Suspension Rigid -
Battery IX 250Wh intube -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 172cm
MD
169cm - 180cm
LG
177cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Montmartre
Suspension Fork
OGV III 12x100
Drivetrain
Rear Derailleur
Cues 1x9v
Cassette
Cues 9v 11-46
Crank
Cues 6000 40d
Pedals
Without pedals
Wheels
Rims
ASY X30
Tires
Overide 700x35 Tube Type
Brakes
Brakes
Rim
Cockpit
Stem
TK-278A (semi-intégrée)
Handlebar
Flat 580 mm
Grips
True grip X Comp
Seat
Saddle
Essenza Plus Moderate
Seatpost
2B WTD 27,2
Motor & Battery
Battery
IX 250Wh intube
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.637 mm | 1.644 mm | 1.651 mm | 1.603 mm |
| Front Center | 624 mm | 641 mm | 658 mm | 679 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 84 mm | 84 mm | 84 mm | 84 mm |
| Stack | 591 mm | 610 mm | 629 mm | 638 mm |
| Reach | 361 mm | 371 mm | 381 mm | 398 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 510 mm | 560 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 185 mm | 205 mm | 225 mm | 235 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1070 mm | 1087 mm | 1104 mm | 1125 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 169 cm | 177 cm | 0 cm |
| Rider Max Height | 172 cm | 180 cm | 185 cm | 194 cm |
