Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
153cm - 170cm
MD
167cm - 179cm
LG
176cm - 189cm
XL
186cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Theoreme GT
Suspension Fork
Raidon 32 100mm
Drivetrain
Rear Derailleur
GX Eagle 12s Lunar
Cassette
GX Eagle 10-52 12 s
Crank
GX Eagle 32 single Dub
Pedals
Without pedals
Wheels
Rims
Red Zone 500
Tires
Force AM Competition Line 29x2.25
Brakes
Brakes
MT 410
Cockpit
Stem
CLS L2 MTB
Handlebar
MTN Rizer Comp 740
Grips
True grip X Comp
Seat
Saddle
X3 Flow Boost
Seatpost
Monobloc forgée alu 0 Offset 30,9 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.498 mm | 1.443 mm | 1.426 mm | 1.382 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 662 mm | 688 mm | 707 mm | 736 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 94 mm | 93 mm | 94 mm | 94 mm |
| Stack | 602 mm | 612 mm | 626 mm | 640 mm |
| Reach | 402 mm | 424 mm | 439 mm | 463 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1084 mm | 1110 mm | 1130 mm | 1159 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 153 cm | 167 cm | 176 cm | 186 cm |
| Rider Max Height | 170 cm | 179 cm | 189 cm | 200 cm |
