Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Fork RockShox Pike Ultimate
-
Groupset GX Eagle Transmission -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 169cm
MD
166cm - 177cm
LG
174cm - 187cm
XL
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Théorème TR 130/120
Suspension Fork
Pike Ultimate RC2 130mm Silver
Drivetrain
Rear Derailleur
GX Eagle AXS T-Type
Cassette
GX Eagle 10-52 12 s
Crank
GX Eagle T-Type 32 CL55
Pedals
Without pedals
Wheels
Rims
Polaris A30 Pro 29''
Tires
Wyrm 29 x 2.40 Tan
Brakes
Brakes
XT M8100
Cockpit
Stem
Mountain Trail TFS
Handlebar
MTN Rizer Trail WCS 780
Grips
True grip X Comp
Seat
Saddle
Terra Ridon X5
Seatpost
Reverb Stealth 125mm 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.438 mm | 1.358 mm | 1.315 mm | 1.276 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 708 mm | 733 mm | 764 mm | 795 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 116 mm | 116 mm | 117 mm | 119 mm |
| Stack | 594 mm | 595 mm | 610 mm | 624 mm |
| Reach | 413 mm | 438 mm | 464 mm | 489 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 66.3 ° | 66.3 ° | 66.3 ° | 66.3 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1141 mm | 1166 mm | 1197 mm | 1228 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 159 cm | 166 cm | 174 cm | 184 cm |
| Rider Max Height | 169 cm | 177 cm | 187 cm | 200 cm |
