Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail Gravel Flatbar
Suspension Fork
OGV III 12x100
Drivetrain
Rear Derailleur
105 R7020 Fitness Disc
Cassette
R7000 11-34
Crank
105 R7000 50/34 Compact
Pedals
Without pedals
Wheels
Rims
Rapid Red 300
Tires
Overide 700x35 Tube Type
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L2
Handlebar
Flat 580 mm
Grips
True grip X Comp
Seat
Saddle
X-LR Air Cross Light SF Rails Ti316
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.547 mm | 1.582 mm | 1.619 mm | 1.637 mm |
| Front Center | 589 mm | 599 mm | 610 mm | 620 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 63 mm | 60 mm |
| Stack | 563 mm | 587 mm | 612 mm | 632 mm |
| Reach | 364 mm | 371 mm | 378 mm | 386 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 545 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 150 mm | 175 mm | 200 mm | 220 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1006 mm | 1017 mm | 1028 mm | 1038 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 74 mm | 73 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 169 cm | 177 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 187 cm | 197 cm |
