Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
SM
160cm - 175cm
MD
172cm - 181cm
LG
178cm - 187cm
XL
184cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tuxedo
Suspension Fork
Axxome II Carbone U.D (380 g)
Drivetrain
Rear Derailleur
Tiagra 10s
Cassette
HG-50 11-34
Crank
Tiagra Compact 50/34
Pedals
Without pedals
Wheels
Rims
Racing 500
Tires
Ultra Sport 25
Brakes
Brakes
Tiagra 4700
Cockpit
Stem
CLS L2
Handlebar
Road Curve Comp
Seat
Saddle
X1 White
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.472 mm | 1.483 mm | 1.527 mm | 1.535 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 574 mm | 590 mm | 600 mm | 620 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 62 mm | 59 mm | 59 mm |
| Stack | 543 mm | 562 mm | 588 mm | 611 mm |
| Reach | 369 mm | 379 mm | 385 mm | 398 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 555 mm | 590 mm |
| Head Tube Angle | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 185 mm | 210 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 974 mm | 990 mm | 1000 mm | 1020 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 172 cm | 178 cm | 184 cm |
| Rider Max Height | 175 cm | 181 cm | 187 cm | 190 cm |
