Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
149cm - 161cm
SM
159cm - 174cm
MD
171cm - 182cm
LG
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BUTTED REYNOLDS 725 TUBESET, 12MMX142MM THRU AXLE, BSA 68mm BOTTOM BRACKET, 1-1/2¨ x 1-1/8¨ TAPERED HEADTUBE, FLAT MOUNT DISC BRAKE, 29.8MM SEAT CLAMP, 27.2mm SEATPOST, 28.6MM FRONT DERAILLEUR CLAMP, HEADSET: TOP ZS44 LOWER EC49, MAX CHAINRINGDS: 53-39-30, TIRE CLEARANCE: 700X50; 650X2.1, FENDER AND REAR RACK EYELETS, COLOR: HONEY/DARK YELLOW
Suspension Fork
100% CARBON, TRIPLE MOUNTS FOR CARGO CAGES, 12MMX100MM THRU AXLE, 1-1/8¨ / 1-1/2¨ TAPERED STEER TUBE, TIRE CLEARANCE: 700X50; 650X2.1, FENDER MOUNTS
Drivetrain
Rear Derailleur
SRAM RIVAL 11SPD
Shift Levers
SRAM RIVAL
Cassette
SRAM XG1150 10-42T 11 speed
Crank
FSA GOSSAMER COMPACT 1X, 36T
Bottom Bracket
FSA THREADED BSA
Chain
SRAM PC1110 11 speed
Pedals
Non included
Wheels
Rims
HUNT 4SEASON GRAVEL DISC X WIDE
Tires
WTB RADDLER 700X44C TCS LIGHT/FAST ROLLING TANWALL
Brakes
Brakes
TRP SPYRE FLAT MOUNT
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY ROAD BEACON, 46CM, 36DEG FLARE, 31.8MM
Headset
FSA NO.9M/CUP/CC//NO.12B
Seat
Saddle
WTB VOLT MEDIUM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.53 mm | 1.57 mm | 1.6 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 593 mm | 593 mm | 616 mm | 631 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 70 mm | 67 mm | 67 mm |
| Stack | 545 mm | 564 mm | 599 mm | 622 mm |
| Reach | 364 mm | 369 mm | 381 mm | 389 mm |
| Top Tube Length | 521 mm | 537 mm | 564 mm | 586 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 490 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 115 mm | 130 mm | 165 mm | 190 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1027 mm | 1027 mm | 1050 mm | 1066 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 714 mm | 754 mm | 790 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 159 cm | 171 cm | 179 cm |
| Rider Max Height | 161 cm | 174 cm | 182 cm | 190 cm |
About this model
Anticosti is part of the Panorama Anticosti model. There are 2 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Panorama Anticosti price was 2241$. In conclusion, this bike price is 9.86% lower than the price of the average Gravel bike.
Anticosti components
Fork material
Anticosti has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Anticosti model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Panorama Anticosti is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 149 cm – 190 cm (4.89 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
