Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival, Easton -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
167cm - 177cm
LG
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BUTTED REYNOLDS 725 TUBESET, ELECTRODEPOSITION SURFACE TREATMENT (CORROSION PROTECTION), 12MMX142MM THRU AXLE, BSA 68mm BOTTOM BRACKET, 1-1/2¨ x 1-1/8¨ TAPERED HEADTUBE, FLAT MOUNT DISC BRAKE, REAR RACK MOUNTS, WATER BOTTLE MOUNTS UNDER AND OVER THE DOWNTUBE, WATER BOTTLE MOUNTS ON SEAT TUBE, GAS TANK MOUNT ON TOP OF TOP TUBE, FRONT DERAILLEUR READY, FENDER MOUNTS, 29.8MM SEAT CLAMP, 27.2mm SEATPOST, 28.6MM FRONT DERAILLEUR CLAMP, HEADSET: TOP ZS44 LOWER EC49, MAX CHAINRING: 46T, TIRE CLEARANCE: 700X50; 650X2.1, FENDER AND REAR RACK EYELETS, COLOR: WASABI GREEN
Suspension Fork
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 700X50MM OR 650X2.1¨, COLOR: WASABI GREEN
Drivetrain
Rear Derailleur
SRAM RIVAL 11SPD
Shift Levers
SRAM RIVAL
Cassette
SUNRACE CSMX8, 11-46T
Crank
EASTON EA90, 38T
Bottom Bracket
EASTON 30MM, BSA
Chain
KMC X11
Pedals
Not included
Wheels
Rims
HUNT 4SEASON GRAVEL DISC X WIDE 700c
Tires
TERAVAIL RUTLAND 700X42 TAN, LIGHT AND SUPPLE
Brakes
Brakes
YOKOZUNA MOTOKO ROAD
Brake Levers
SRAM RIVAL
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY COMP VENTURE MAX II, 46CM
Headset
FSA NO.9M/CUP/CC//NO.12B
Seat
Saddle
WTB VOLT MEDIUM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm |
| Front Center | 616 mm | 631 mm | 646 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 71 mm | 68 mm | 65 mm |
| Stack | 581 mm | 606 mm | 632 mm |
| Reach | 377 mm | 388 mm | 400 mm |
| Top Tube Length | 547 mm | 566 mm | 591 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 475 mm | 505 mm | 525 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 140 mm | 165 mm | 190 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1053 mm | 1068 mm | 1084 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 737 mm | 772 mm | 802 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 167 cm | 180 cm |
| Rider Max Height | 165 cm | 177 cm | 188 cm |
About this model
Anticosti completes the Panorama Anticosti model. Panorama launched 2 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Panorama Anticosti price was 2603$. In conclusion, this bike price is 5.73% more expensive than the price of the average Gravel bike.
Anticosti components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the Anticosti bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Anticosti comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 157 cm – 188 cm (5.15 ft – 6.17 ft). In conclusion, finding one for you shouldn’t be a problem.
