Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Rival -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
167cm - 177cm
LG
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 700X50MM OR 650X2.1¨, COLOR: WASABI GREEN
Drivetrain
Rear Derailleur
SRAM RIVAL 11SPD
Shift Levers
SRAM RIVAL
Cassette
SUNRACE CSMX8, 11-46T
Crank
EASTON EA90, 38T
Bottom Bracket
EASTON 30MM, BSA
Chain
KMC X11
Pedals
Not included
Wheels
Rims
HUNT 4SEASON GRAVEL DISC X WIDE 700c
Tires
MAXXIS RAMBLER, 700X45, EXO/TR, 60TPI, TANWALL
Brakes
Brakes
SRAM RIVAL
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY COMP VENTURE MAX II, 46CM
Headset
FSA NO.9M/CUP/CC//NO.12B
Seat
Saddle
WTB VOLT MEDIUM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.551 mm | 1.572 mm | 1.59 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm |
| Front Center | 616 mm | 631 mm | 646 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 71 mm | 68 mm | 65 mm |
| Stack | 574 mm | 599 mm | 625 mm |
| Reach | 370 mm | 381 mm | 393 mm |
| Top Tube Length | 540 mm | 559 mm | 584 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 475 mm | 505 mm | 525 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 140 mm | 165 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1046 mm | 1061 mm | 1077 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 730 mm | 765 mm | 795 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 167 cm | 180 cm |
| Rider Max Height | 165 cm | 177 cm | 188 cm |
