Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset SLX -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 164cm
MD
161cm - 179cm
LG
176cm - 187cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
TAILORED CARBON CONSTRUCTION, 15MMX150MM AXLE, ANYTHING CAGES MOUNTS, TAPERED 1-1/8¨ / 1-1/2¨
Drivetrain
Rear Derailleur
SHIMANO SLX M7100, 12s
Shift Levers
SHIMANO SLX M7100, 12s
Cassette
SHIMANO DEORE M6100-12, 10-51T, 12s
Crank
RACE FACE RIDE, 28T CINCH DM STEEL CHAINRING
Bottom Bracket
RACE FACE TEAM BSA AXE 24mm
Chain
KMC X12, 12s
Pedals
Not included
Wheels
Rims
SUN RINGLE MULEFÜT 80SL V2, 27.5?, 32 HOLES, SUNRINGLE SRC MICROSPLINE HUB
Tires
VEE SNOW AVALANCHE 27.5X4.5?, 120TPI, TUBELESS READY, STUDDABLE
Brakes
Brakes
SRAM LEVEL
Cockpit
Stem
RITCHEY MTB trail, Alloy 31.8X45mm
Handlebar
RITCHEY MTN Comp 10D Rizer, 31.8x800mm, 20mm rise, 10D backswept
Headset
FSA NO.9M/NO.12B
Seat
Saddle
WTB PURE
Seatpost
KS E20I DROPPER POST, 100/125/150MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.499 mm | 1.398 mm | 1.406 mm | 1.361 mm |
| Bottom Bracket Height | 297 mm | 297 mm | 297 mm | 297 mm |
| Front Center | 666 mm | 705 mm | 713 mm | 726 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 91 mm | 91 mm | 90 mm | 97 mm |
| Stack | 592 mm | 601 mm | 610 mm | 615 mm |
| Reach | 395 mm | 430 mm | 434 mm | 452 mm |
| Top Tube Length | 567 mm | 608 mm | 621 mm | 630 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72 ° | 72 ° |
| Seat Tube Length | 381 mm | 425 mm | 475 mm | 525 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1130 mm | 1169 mm | 1177 mm | 1190 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 697 mm | 748 mm | 798 mm | 836 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 161 cm | 176 cm | 184 cm |
| Rider Max Height | 164 cm | 179 cm | 187 cm | 195 cm |
