Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Travel Front 120mm -
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes SRAM Level T Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
165cm - 180cm
LG
177cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SUSPENSION FORK COMPATIBLE. GEO CORRECTED FOR 120MM FATBIKE FORK OR 140MM 29IN FORK
Drivetrain
Rear Derailleur
SHIMANO DEORE M6100 12s
Shift Levers
SHIMANO DEORE M6100 12s
Cassette
SHIMANO DEORE M6100, 10-51T, 12s
Crank
RACE FACE RIDE, 28T CINCH DM STEEL CHAINRING
Bottom Bracket
RACE FACE TEAM BSA AXE 24mm
Chain
KMC X12, 12s
Pedals
Not included
Wheels
Rims
SUN RINGLE MULEFÜT 80SL V2, 27.5?, 32 HOLES, PANORAMA SPEC STAR RATCHET REAR HUB.
Tires
TERRENE CAKE EATER, LIGHT, 120 TPI, 27.5X4.5, STUDDABLE
Brakes
Brakes
SRAM LEVEL T
Cockpit
Stem
RACE FACE RIDE, 35MM, 50MM X 6DEG
Handlebar
RACE FACE CHESTER 35MM, 35MM RISE, 780MM
Headset
FSA NO.9M/NO.12B
Seat
Saddle
WTB PURE
Seatpost
OPTION 2: KS RAGE-I DROPPER POST,125/150/170MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.437 mm | 1.378 mm | 1.333 mm |
| Bottom Bracket Height | 290 mm | 290 mm | 290 mm |
| Front Center | 729 mm | 759 mm | 788 mm |
| Rake | 51 mm | 52 mm | 51 mm |
| Trail | 99 mm | 98 mm | 99 mm |
| Stack | 618 mm | 627 mm | 640 mm |
| Reach | 430 mm | 455 mm | 480 mm |
| Top Tube Length | 590 mm | 618 mm | 646 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 380 mm | 410 mm | 450 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1171 mm | 1201 mm | 1231 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 693 mm | 718 mm | 756 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 165 cm | 177 cm |
| Rider Max Height | 167 cm | 180 cm | 188 cm |
