Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset microSHIFT XLE, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REYNOLDS 525 FRAME, BRAKE STD: I.S. MOUNT, REAR RACK MOUNTS, FENDER MOUNTS, TRIPLE WATER BOTTLE MOUNTS UNDER THE DOWNTUBE, DOUBLE WATER BOTTLE MOUNTS OVER THE DOWNTUBE, DOUBLE WATER BOTTLE MOUNTS ON THE SEAT TUBE, INTEGRATED KSA-18 KICKSTAND PLATE, EXTRA SPOKES SUPPORT, ELECTRODEPOSITION SURFACE TREATMENT (CORROSION PROTECTION), 12MMX142MM REAR SPACING, BSA 68mm BOTTOM BRACKET, 1-1/8¨ HEAD TUBE, HEADSET: TOP EC34 LOWER EC34, DIA 29.8MM SEAT POST CLAMP, DIA 27.2MM SEAST POST, COLLET DE DÉRAILLEUR AVANT DIA 28.6MM, MAX TIRE CLEARANCE WITHOUT FENDER: 700X50MM, MAX TIRE CLEARANCE WITH FENDER: 700X44MM
Suspension Fork
CUSTOM CR-MO 4130, BRAKE STD: I.S. MOUNT, PANNIER RACK MOUNTS, FENDER MOUNTS, TRIPLE CARGO CAGE MOUNTS, 12MMX100MM SPACING, STEER TUBE: 1-1/8¨, MAX TIRE CLEARANCE WITHOUT FENDER: 700X50MM, MAX TIRE CLEARANCE WITH FENDER: 700X42MM
Drivetrain
Rear Derailleur
MICROSHIFT XLE 11S
Front Derailleur
MICROSHIFT XLE
Shift Levers
MICROSHIFT BAR END 2X11
Cassette
MICROSHIFT XLE 11-42T
Crank
FSA OMEGA 2X MEGAEXO, 46/30T
Bottom Bracket
FSA MEGAEXO BB-4000
Chain
SHIMANO HG 601
Pedals
Not included
Wheels
Front Hub
NOVATEC D791SB/D792SB
Rear Hub
NOVATEC D791SB/D792SB
Rims
DB-30, 36 SPOKES, DOUBLE WALLED, REINFORCING EYELETS
Tires
WTB BYWAY 700X44 120 TPI DUAL DNA SG2
Brakes
Brakes
AVID BB7R
Brake Levers
SRAM BL500 BLACK
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY COMP ERGO MAX, 31.8MM X 440MM
Headset
FSA ORBIT UF, 1-1/8 EC34
Seat
Saddle
PANORAMA SPEC, 265mm X 140mm
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 260 mm |
| Front Center | 592 mm | 606 mm | 626 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 67 mm | 67 mm |
| Stack | 565 mm | 585 mm | 615 mm |
| Reach | 367 mm | 375 mm | 385 mm |
| Top Tube Length | 530 mm | 550 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 480 mm | 515 mm | 550 mm |
| Head Tube Angle | 71.8 ° | 71.8 ° | 71.8 ° |
| Head Tube Length | 110 mm | 130 mm | 163 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1031 mm | 1045 mm | 1065 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm |
| Standover Height | 741 mm | 773 mm | 806 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 176 cm |
| Rider Max Height | 172 cm | 179 cm | 188 cm |
About this model
Forillon is part of the Panorama Forillon model. There are 2 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Touring bikes
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Panorama released this model in 2023, its price was 1735$. In conclusion, this bike price is 72.29% more expensive than the price of the average Touring bike.
Overview of components
Fork material
Forillon has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
As for the wheels, Panorama Forillon 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 162 cm – 188 cm (5.31 ft – 6.17 ft). In conclusion, you won’t have a problem finding one that suits you.
