Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset CUES -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
, HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 29X2.25¨, FLAT MOUNT BRAKE STD, COLOR: DARK EGGPLANT
Drivetrain
Rear Derailleur
SHIMANO CUES 6000, 11s
Front Derailleur
N/A
Shift Levers
SHIMANO CUES 6030
Cassette
SHIMANO LG400, 11-50T
Crank
EASTON EA90, 38T
Bottom Bracket
EASTON 30mm, BSA
Chain
SHIMANO LG500, 11s
Pedals
Not included
Wheels
Rims
OPTION 2:, WE ARE ONE, REVIVE, INDUSTRY NINE 1/1 HUBS
Tires
MAXXIS RAMBLER, 700X45, EXO/TR, 60TPI, TANWALL
Brakes
Brakes
SHIMANO CUES 6030
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY COMP BUTANO V2, 44CM (S), 46CM (M,L)
Headset
FSA NO.42 IS
Seat
Saddle
WTB SILVERADO MEDIUM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.504 mm | 1.528 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm |
| Front Center | 619 mm | 636 mm | 651 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 71 mm | 71 mm | 71 mm |
| Stack | 573 mm | 591 mm | 611 mm |
| Reach | 382 mm | 393 mm | 400 mm |
| Top Tube Length | 546 mm | 562 mm | 575 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1040 mm | 1057 mm | 1072 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 745 mm | 770 mm | 790 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 176 cm |
| Rider Max Height | 172 cm | 179 cm | 188 cm |
