Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
100% CARBON, TRIPLE CARGO CAGE MOUNTS, 15MMX110MM BOOST SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 29¨X2.6¨ or 27.5¨X2.8¨, 480mm LENGTH (100mm SUSPENSION FORK EQUIVALENT AT 25% SAG)
Drivetrain
Rear Derailleur
SHIMANO GRX RX822, SGS 12 SPEEDS
Shift Levers
SHIMANO GRX RX610 (left brake/shift lever compatible with 2x front derailleur)
Cassette
SHIMANO M7100-12, 10-51T, 12 SPEEDS
Crank
RACE FACE AEFFECT, 34T SHI12 CINCH DM CHAINRING, 170mm
Bottom Bracket
RACE FACE TEAM BSA 24mm SPINDLE
Chain
SHIMANO M7100, 12 SPEEDS
Pedals
Not included
Wheels
Rims
WTB STi30 / SHIMANO TC500 (FRONT) / TC600 (REAR), 32 HOLES, CENTERLOCK, MICROSPLINE
Tires
MAXXIS IKON, 29X2.20, 3C/EXO/TR, 60TPI, TANWALL
Brakes
Brakes
SHIMANO GRX RX400
Cockpit
Stem
RITCHEY MTB trail, Alloy BBK 31.8X60mm
Handlebar
RITCHEY ROAD CMP BEACON, 52cm WIDE, 80mm DROP, 36d FLARE
Headset
FSA NO.9M/NO.12B
Seat
Saddle
WTB PURE
Seatpost
KALLOY SP-3D2, 27.2mm X400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.642 mm | 1.679 mm | 1.695 mm |
| Front Center | 625 mm | 639 mm | 663 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 100 mm | 100 mm | 100 mm |
| Stack | 609 mm | 633 mm | 661 mm |
| Reach | 371 mm | 377 mm | 390 mm |
| Top Tube Length | 546 mm | 564 mm | 592 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 415 mm | 470 mm | 515 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 125 mm | 155 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1066 mm | 1080 mm | 1104 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 750 mm | 810 mm | 860 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 171 cm | 179 cm |
| Rider Max Height | 174 cm | 182 cm | 190 cm |
