Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Travel Front 120mm -
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes SRAM Level T Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 169cm
MD
166cm - 179cm
LG
176cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
CUSTOM CARBON CONSTRUCTION, AXLE TO CROWN ADAPTED TO 120MM SUSPENSION (29”), THREE PACK MOUNTS ON EACH SIDE, 15MMX150MM AXLE, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAXIMUM TIRE CLEARANCE: 27.5¨X4.5¨; 26¨X5¨ ; 29¨X3¨, MAX ROTOR: 203mm, WEIGHT: 660g
Drivetrain
Rear Derailleur
SHIMANO DEORE M6100 12s
Shift Levers
SHIMANO DEORE M6100 12s
Cassette
SHIMANO DEORE M6100-12, 10-51T, 12s
Crank
RACE FACE TURBINE, 170MM, CINCH, 2X SPINDLES (2 DIFFERENT Q-FACTOR) INCLUDED, 28T CINCH DM ALLOY CHAINRING
Bottom Bracket
RACE FACE PF 30mm SPINDLE
Chain
KMC X12, 12s
Pedals
Not included
Wheels
Rims
SUN RINGLE MULEFÜT 80SL V2, 27.5?, 32 HOLES, SUNRINGLE SRC MICROSPLINE HUB
Tires
TERRENE CAKE EATER, LIGHT, 120 TPI, 27.5X4.5, STUDDABLE
Brakes
Brakes
SRAM LEVEL T
Cockpit
Stem
RACE FACE RIDE, 35MM, 50MM X 6DEG
Handlebar
RACE FACE CHESTER 35MM, 35MM RISE, 780MM
Headset
FSA NO.9M/NO.12B
Seat
Saddle
WTB PURE
Seatpost
KS E20I DROPPER POST, 100/125/150MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.471 mm | 1.409 mm | 1.374 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm |
| Front Center | 686 mm | 725 mm | 741 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 105 mm | 93 mm | 106 mm |
| Stack | 612 mm | 620 mm | 635 mm |
| Reach | 416 mm | 440 mm | 462 mm |
| Top Tube Length | 585 mm | 612 mm | 637 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 425 mm | 480 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1127 mm | 1166 mm | 1182 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 702 mm | 745 mm | 811 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 166 cm | 176 cm |
| Rider Max Height | 169 cm | 179 cm | 195 cm |
