Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Chorus, Super Record -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 167cm
SM
165cm - 171cm
MD
168cm - 180cm
LG
177cm - 187cm
XL
184cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Parapera Carbon Aero
Drivetrain
Rear Derailleur
Campagnolo Chorus 12-speed
Cassette
Campagnolo Super Record wireless 12-speed, 10-29
Crank
Campagnolo Super Record wireless 2-fold 29-45 new SuperCompact
Pedals
without
Wheels
Rims
Mavic Allroad S Gravel
Brakes
Brakes
Depending on the Campa group you choose
Cockpit
Stem
Parapera Aluminum Super Light
Handlebar
Syntace Racelite 440mm
Seat
Saddle
without
Seatpost
Parapera Carbon extralight
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.373 mm | 1.407 mm | 1.447 mm | 1.467 mm | 1.473 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 573 mm | 590 mm | 594 mm | 600 mm | 620 mm |
| Rake | 46 mm | 51 mm | 45 mm | 45 mm | 44 mm |
| Trail | 72 mm | 63 mm | 66 mm | 60 mm | 61 mm |
| Stack | 508 mm | 532 mm | 557 mm | 578 mm | 601 mm |
| Reach | 370 mm | 378 mm | 385 mm | 394 mm | 408 mm |
| Top Tube Length | 510 mm | 526 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 114 mm | 137 mm | 158 mm | 178 mm | 202 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 410 mm | 410 mm |
| Wheelbase | 969 mm | 986 mm | 990 mm | 1000 mm | 1020 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 168 cm | 177 cm | 184 cm |
| Rider Max Height | 167 cm | 171 cm | 180 cm | 187 cm | 201 cm |
