Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 167cm
SM
165cm - 171cm
MD
168cm - 180cm
LG
177cm - 187cm
XL
184cm - 201cm
XXL
195cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Parapera Gravel Carbon extralight, ohne Ösen
Drivetrain
Rear Derailleur
Campagnolo Ekar 1x 13
Cassette
EKAR 13-fold 10-44
Crank
EKAR 13-speed 40T.
Pedals
without
Wheels
Rims
Campagnolo Levante 2024
Brakes
Brakes
Campagnolo EKAR
Cockpit
Stem
Parapera Aluminum Super Light
Handlebar
Parapera SpeedGravel Carbon 420mm / 18 degree flare
Seat
Saddle
Selle Italia SLR Superflow Kit Carbonio black
Seatpost
Schmolke Carbon TLO up to 90kg
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.443 mm | 1.497 mm | 1.52 mm | 1.515 mm | 1.561 mm | 1.561 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 274 mm | 274 mm | 276 mm | 276 mm |
| Front Center | 604 mm | 606 mm | 616 mm | 631 mm | 641 mm | 656 mm |
| Rake | 56 mm | 62 mm | 62 mm | 61 mm | 61 mm | 60 mm |
| Trail | 64 mm | 51 mm | 51 mm | 52 mm | 52 mm | 54 mm |
| Stack | 541 mm | 560 mm | 576 mm | 591 mm | 612 mm | 629 mm |
| Reach | 375 mm | 374 mm | 379 mm | 390 mm | 392 mm | 403 mm |
| Top Tube Length | 520 mm | 535 mm | 555 mm | 570 mm | 585 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 110 mm | 125 mm | 145 mm | 160 mm | 185 mm | 200 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1022 mm | 1024 mm | 1035 mm | 1050 mm | 1061 mm | 1076 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 75 mm | 75 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 168 cm | 177 cm | 184 cm | 195 cm |
| Rider Max Height | 167 cm | 171 cm | 180 cm | 187 cm | 201 cm | 205 cm |
