Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Chorus, Super Record -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 167cm
SM
165cm - 171cm
MD
168cm - 180cm
LG
177cm - 187cm
XL
184cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Parapera Carbon SpeedGravel
Drivetrain
Rear Derailleur
Campagnolo Chorus 12-speed
Cassette
Campagnolo Super Record wireless 12-speed, 10-29
Crank
Campagnolo Super Record wireless 2-fold 29-45 new SuperCompact
Pedals
without
Wheels
Rims
Campagnolo Shamal Carbon 28 inches
Brakes
Brakes
Depending on the Campa group you choose
Cockpit
Stem
Parapera Aluminum Super Light
Handlebar
Syntace Racelite 440mm
Seat
Saddle
without
Seatpost
Parapera Carbon extralight
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.357 mm | 1.381 mm | 1.421 mm | 1.441 mm | 1.475 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 577 mm | 584 mm | 590 mm | 604 mm | 619 mm |
| Rake | 44 mm | 46 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 65 mm | 63 mm | 60 mm | 60 mm |
| Stack | 513 mm | 529 mm | 550 mm | 575 mm | 599 mm |
| Reach | 378 mm | 383 mm | 387 mm | 399 mm | 406 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 575 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 114 mm | 129 mm | 149 mm | 174 mm | 199 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 410 mm | 410 mm |
| Wheelbase | 975 mm | 982 mm | 988 mm | 1004 mm | 1019 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 165 cm | 168 cm | 177 cm | 184 cm |
| Rider Max Height | 167 cm | 171 cm | 180 cm | 187 cm | 201 cm |
