Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Fork X-Fusion RC32
-
Groupset Deore, Suntour -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL alloy hardtail XC-trail, 12×148 mm
Suspension Fork
X-FUSION RC32, 130mm travel, TA 15×110
Drivetrain
Rear Derailleur
SHIMANO Deore M5100, 11s
Shift Levers
SHIMANO Deore M5100
Cassette
SHIMANO Deore M5100-11, 11-51t
Crank
WHEEL TOP SR-11-C, 32t
Wheels
Rims
PATROL, alloy, 32h
Tires
MAXXIS Rekon Race, 29×2.25
Brakes
Brakes
SHIMANO MT200
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.4 mm | 1.337 mm | 1.283 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 724 mm | 749 mm | 773 mm | 801 mm |
| Rake | 2 mm | 2 mm | -1 mm | 2 mm |
| Trail | 157 mm | 157 mm | 160 mm | 157 mm |
| Stack | 630 mm | 630 mm | 635 mm | 639 mm |
| Reach | 425 mm | 450 mm | 475 mm | 498 mm |
| Top Tube Length | 606 mm | 631 mm | 657 mm | 682 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 420 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1157 mm | 1182 mm | 1206 mm | 1234 mm |
| Bottom Bracket Drop | -62 mm | -62 mm | -62 mm | -62 mm |
| Standover Height | 704 mm | 708 mm | 738 mm | 780 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
094 is part of the Patrol 094 model. Patrol released 1 bike variation of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
094 components
Fork
The fork installed on this bike is the X-Fusion RC32 model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the 094 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Patrol 094 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
