Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL alloy all-mountain, 12×157 mm Super Boost, 160mm travel
Suspension Fork
FOX 38 Factory, 170mm travel
Rear Shock
FOX Float X2 Performance
Drivetrain
Rear Derailleur
SHIMANO Deore XT M8100, 12s
Shift Levers
SHIMANO Deore XT M8100-R
Cassette
SHIMANO SLX M7100, 12s, 12-51t
Crank
SHIMANO Deore XT M8130-1, 32t
Bottom Bracket
BSA, 73mm, threaded
Wheels
Rims
SUNringlé Düroc SD37 rims with SHIMANO SLX hubs
Tires
MAXXIS Minion DHF EXO/TR (F), DHR II foldable (R), 29×2.60
Brakes
Brakes
SHIMANO M8120
Seat
Seatpost
X FUSION Manic, 30.9mm, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.349 mm | 1.293 mm | 1.28 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 755 mm | 777 mm | 800 mm | 819 mm |
| Rake | 21 mm | 21 mm | 23 mm | 22 mm |
| Trail | 151 mm | 151 mm | 149 mm | 150 mm |
| Stack | 609 mm | 614 mm | 614 mm | 627 mm |
| Reach | 435 mm | 455 mm | 475 mm | 490 mm |
| Top Tube Length | 566 mm | 587 mm | 609 mm | 627 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 420 mm | 455 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1199 mm | 1221 mm | 1244 mm | 1263 mm |
| Bottom Bracket Drop | -27 mm | -27 mm | -27 mm | -27 mm |
| Standover Height | 716 mm | 719 mm | 722 mm | 724 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
691 evo is part of the Patrol 691 model. Patrol launched 5 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4699$. Comparing the average cost of an Enduro bike to this one, you will see that 691 evo price is 30.56% more expensive.
691 evo components
Fork
The fork installed on this bike is the Fox Factory Float 38 model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Patrol 691 evo bike has the FOX Float X2 Performance model installed, and has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the 691 evo bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The 691 evo comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
691 evo comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
