Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL 09 carbon, 12×148 mm Boost
Suspension Fork
ROCKSHOX Recon RL, 130mm travel, 15×110, 51mm offset
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12s
Shift Levers
SRAM SX Eagle
Cassette
SRAM PG-1210 Eagle, 12s, 11-50t
Crank
SRAM NX Eagle, 32t
Wheels
Rims
PATROL, alloy, 32h
Tires
VEE TIRE Crown Gem, 29×2.30
Brakes
Brakes
SHIMANO MT400
Seat
Seatpost
X FUSION Manic, 31.6mm, 150mm (S/M) – 170mm (L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.4 mm | 1.337 mm | 1.29 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 724 mm | 749 mm | 776 mm | 803 mm |
| Rake | 2 mm | 2 mm | 2 mm | 0 mm |
| Trail | 157 mm | 157 mm | 157 mm | 159 mm |
| Stack | 630 mm | 630 mm | 635 mm | 645 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 606 mm | 631 mm | 655 mm | 685 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 420 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 115 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1147 mm | 1172 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | -62 mm | -62 mm | -62 mm | -62 mm |
| Standover Height | 701 mm | 709 mm | 743 mm | 781 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
c091 completes the Patrol C091 model. There are 2 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Patrol released this model in 2023, its price was 2199$. Doing a quick comparison, we notice that c091 price is 25.6% lower than the average cost of a Trail bike.
c091 components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the c091 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The c091 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Patrol c091 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Patrol c091 includes a dropper post. Therefore, climbing or descending will be a breeze.
