Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Fork X-Fusion RC32
-
Groupset Deore -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL 09 carbon, 12×148 mm Boost
Suspension Fork
X-FUSION RC32, 130mm travel, TA 15×110
Drivetrain
Rear Derailleur
SHIMANO Deore M5100, 11s
Shift Levers
SHIMANO Deore M5100
Cassette
SHIMANO Deore M5100-11
Crank
SHIMANO Deore M5100-1
Wheels
Rims
PATROL, alloy, 32h
Tires
VEE TIRE Mission, 29×2.30
Brakes
Brakes
SHIMANO MT200
Seat
Seatpost
KS KSP900-I remote, 31.6mm, 150mm (S/M) – 175mm (L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.4 mm | 1.337 mm | 1.29 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 724 mm | 749 mm | 776 mm | 803 mm |
| Rake | 2 mm | 2 mm | 2 mm | 0 mm |
| Trail | 157 mm | 157 mm | 157 mm | 159 mm |
| Stack | 630 mm | 630 mm | 635 mm | 645 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 606 mm | 631 mm | 655 mm | 685 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 420 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 115 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1147 mm | 1172 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | -62 mm | -62 mm | -62 mm | -62 mm |
| Standover Height | 701 mm | 709 mm | 743 mm | 781 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
c093 is part of the Patrol C093 model. Patrol launched 2 bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Patrol c093 price was 1699$. Doing a quick comparison, we notice that c093 price is 62.57% smaller than the average cost of a Trail bike.
Overview of components
Fork
This bike has the X-Fusion RC32 fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Patrol c093 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Patrol c093 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
c093 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Patrol c093 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
