Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 110mm -
Fork X-Fusion SLIDE
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery SMP, 630Wh -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL E-ZERO alloy, 12×148 mm
Suspension Fork
X FUSION Slide Boost RC, 110mm travel, 51mm offset
Drivetrain
Rear Derailleur
SHIMANO Deore M5100, 11s
Shift Levers
SHIMANO Deore M5100
Cassette
SHIMANO Deore M5100, 11-speed, 11-42t
Crank
SHIMANO E6100, SM-CRE80-12-B, 34t
Wheels
Rims
PATROL MD35 rims with SHIMANO MT400 hubs
Tires
MAXXIS Rekon, 29×2.4WT, EXO/TR
Brakes
Brakes
SHIMANO MT420
Cockpit
Stem
Patrol Enduro
Handlebar
Patrol Enduro
Motor & Battery
Motor
SHIMANO Steps E7000
Battery
SMP, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.547 mm | 1.431 mm | 1.354 mm | 1.321 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm | 328 mm |
| Front Center | 659 mm | 692 mm | 712 mm | 737 mm |
| Rake | 19 mm | 20 mm | 16 mm | 19 mm |
| Trail | 120 mm | 119 mm | 123 mm | 120 mm |
| Stack | 608 mm | 608 mm | 608 mm | 617 mm |
| Reach | 393 mm | 425 mm | 449 mm | 467 mm |
| Top Tube Length | 567 mm | 599 mm | 620 mm | 644 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 445 mm | 470 mm | 495 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1120 mm | 1153 mm | 1173 mm | 1198 mm |
| Bottom Bracket Drop | -45 mm | -45 mm | -45 mm | -45 mm |
| Standover Height | 709 mm | 719 mm | 720 mm | 721 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
e-zero sl is part of the Patrol E E Zero model. There are 6 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry e-bikes
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The X-Fusion SLIDE is included from the factory. It has a travel distance of 110mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the e-zero sl e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The e-zero sl has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
