Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour M 3010
-
Groupset Tourney -
Suspension Hardtail -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
SR SUNTOUR M3010
Drivetrain
Rear Derailleur
SHIMANO Tourney RD-TY200
Front Derailleur
SHIMANO Tourney FD-TY510
Shift Levers
SHIMANO SL-RS36 Revoshift
Cassette
SHIMANO MF-TZ500-6, 14-28T
Crank
SAMOX, SAC08-459, 48/38/28T
Chain
KMC, Z-6
Pedals
Polymer Pedal
Wheels
Rims
DBM-2
Tires
VEE TIRE City Cruz
Brakes
Brakes
V-Brake
Cockpit
Stem
Quill-Vorbau
Handlebar
Aluminium
Headset
FSA B-52S 1-1/8”
Seat
Saddle
PEGASUS Trekking
Seatpost
Aluminium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
