Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
SR SUNTOUR NEX-E25
Drivetrain
Rear Derailleur
SHIMANO Cues RD-U3020
Front Derailleur
SHIMANO Cues FD-U4010-L
Shift Levers
SHIMANO Cues SL-U4000 shifter
Cassette
SHIMANO CS-LG300 9-speed 11-36T
Crank
SHIMANO FC-U4010
Chain
SHIMANO Linkglide CN-LG500
Pedals
ZECURE Trekking pedal
Wheels
Front Hub
SHIMANO Acera Hub dynamo DH-3D37NT
Rear Hub
SHIMANO FH-QC300-HM
Rims
28 Zoll
Tires
SCHWALBE Citizen K-Guard with reflective stripes
Brakes
Brakes
Hydraulic disc brake
Cockpit
Stem
ZECURE adjustable ahead stem
Handlebar
ZECURE
Headset
FSA, NO.57SC Tapered
Seat
Saddle
ZECURE Comfort Men/ Comfort Women / Comfort Plus
Seatpost
ZECURE 30,9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
