Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 47mm -
Fork Suntour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 rigide
Suspension Fork
SR SUNTOUR XCT-HLO débattement de 100 mm verrouillage hydraulique
Drivetrain
Rear Derailleur
Shimano Acera
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus 24 speeds
Cassette
Shimano Altus
Crank
SR SUNTOUR 170 mm (38/43) / 175 mm (48/53)
Pedals
Resin - steel
Wheels
Front Hub
Aluminum
Rear Hub
Aluminum
Rims
Tec aluminum 27.5"
Tires
Kenda Small Black Eight Pro
Brakes
Brakes
Tektro 160 / 160 mm hydraulic discs
Cockpit
Stem
Tec Obvius 60 x 31,8 mm / 70 x 31,8 mm / 80 x 31,8 mm / 90 x 31,8 mm
Handlebar
Tec Obvius Rise Bar 700 x 31.8 mm
Seat
Saddle
Tec Unicus
Seatpost
Tec Obvius 31.6 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Top Tube Length | 577 mm | 601 mm | 630 mm | 656 mm |
| Seat Tube Angle | 67.1 ° | 67.1 ° | 66.6 ° | 66.6 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Front Travel | 47 mm | 47 mm | 47 mm | 47 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
