Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TorayCa T1100 1K Dream Carbon with Nanoalloy Technology, Italian BB, UCI Approved
Suspension Fork
maat onda fork. tapered head tube
Drivetrain
Cassette
singlespeed freehub
Bottom Bracket
custom italian
Chain
singlespeed chain
Cockpit
Handlebar
most bar tape
Seat
Seatpost
Pinarello Aero Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42.5cm | 45cm | 47cm | 48.5cm | 50cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.1 mm | 1.1 mm | 1.12 mm | 1.11 mm | 1.13 mm |
| Bottom Bracket Height | 290 mm | 290 mm | 290 mm | 290 mm | 290 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Stack | 475 mm | 490 mm | 505 mm | 519 mm | 534 mm |
| Reach | 432 mm | 444 mm | 452 mm | 468 mm | 474 mm |
| Top Tube Length | 552 mm | 567 mm | 587 mm | 607 mm | 617 mm |
| Seat Tube Angle | 76 ° | 76 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 455 mm | 480 mm | 500 mm | 515 mm | 530 mm |
| Head Tube Angle | 73.5 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 80 mm | 95 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 382 mm | 382 mm | 382 mm | 382 mm | 382 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Maat Italia is part of the Pinarello Maat model. Pinarello launched 11 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Track bikes average price
If you want to purchase a solid Track bike, it is important to know that the average cost is 1503$. However, you could also get a good Track bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Maat Italia components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Pinarello Maat Italia 2022, has a 700c model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
