Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 heat treated aluminium w/ double-butted tubes
Suspension Fork
Carbon blade, straight 1-1/8 alloy steerer w/ mudguard mounts
Drivetrain
Rear Derailleur
Shimano 105 5800 11 speed
Front Derailleur
Shimano 105 5800 31.8mm band on
Shift Levers
Shimano 105 5800
Cassette
Shimano 105 5800 11-28T
Bottom Bracket
Prowheel BB-68 external threaded
Chain
KMC X11
Pedals
Supplied
Wheels
Front Hub
Loose ball bearing 32H QR
Rear Hub
Loose ball bearing 32H QR
Rims
Alloy double wall 700c, 32H
Tires
Schwalbe Lugano 700x25c, K-Guard
Brakes
Brakes
Tektro R315 dual pivot, 57mm drop
Cockpit
Stem
Pinnacle alloy, +/- 3 degree, S/M - 90mm, L/XL - 105mm
Handlebar
Pinnacle 6061 alloy 125mm drop, 80mm reach, width; S/M - 420mm, L/XL- 440mm
Headset
FSA No.10, internal 1-1/8
Seat
Saddle
Pinnacle Mens
Seatpost
Pinnacle aluminium 350mm x 27.2
About this model
Laterite 3 is a Pinnacle E Laterite model. 1 e-bike variation carries this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race e-bikes average price
Our math shows that the average cost of a dependable Race e-bike is 4156$. However, you could also get a good Race e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Race e-bikes average weight
On a deeper look, we notice that the average weight of a Race e-bike is 8.47 kg (18.67 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Pinnacle Laterite 3 it’s weighing 9.6 kg (21.16 lbs). At this weight, is considerably heavier than average. In short, the average Race e-bike weight is 13.34% lower than this one.
Laterite 3 components
Fork material
The fork on this e-bike is made out of carbon, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Laterite 3 e-bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Pinnacle Laterite 3 has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Pinnacle Laterite 3 2018 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
