Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 100mm -
Fork Manitou Circus Expert
-
Suspension Hardtail -
Brakes SRAM Level Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Point
Suspension Fork
Manitou Circus Expert 34 - 100mm
Drivetrain
Cassette
Singlespeed Cog - 16t
Crank
Two-piece crank arms with integrated 24mm axle - 28t
Chain
KMC Z1eHX Singlespeed
Wheels
Rims
ALEX FR30 Double Wall Rim/Novatec S-Team Hubs - 26”, 20x110 F/10x135 R
Tires
Maxxis Holy Roller 26" x 2.2", Maxxis Holy Roller 26" x 2.2"
Brakes
Brakes
SRAM Level 2-piston (rear only)
Cockpit
Stem
Spank Spoon - 33mm
Handlebar
Spank Spoon - 785mm
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Integrated Cartridge
Seat
Saddle
Phoenix DJ
Seatpost
Phoenix DJ Direct Mount Aluminum 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | OS |
|---|---|
| Stack Reach Ratio | 1.293 mm |
| Bottom Bracket Height | 325 mm |
| Front Center | 677 mm |
| Rake | 38 mm |
| Trail | 94 mm |
| Stack | 551 mm |
| Reach | 426 mm |
| Top Tube Length | 605 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 68.5 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 385 mm |
| Wheelbase | 1061 mm |
| Bottom Bracket Drop | 20 mm |
| Wheels | 26" |
| Rider Min Height | 120 cm |
