Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 164cm
SM
161cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Vault
Suspension Fork
Pivot Vault Carbon
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2 9250 12-Speed
Shift Levers
Shimano Dura Ace 9270 12-Speed
Cassette
Shimano Dura Ace HG-9200 12 Speed 11-34t
Crank
Shimano Dura Ace 9200 50/34t - 165mm(XS), 172.5mm(SM-MD), 175mm(LG-XL)
Chain
Shimano CN-M9100 12-Speed
Wheels
Rims
DT Swiss CR 1600 SPLINE 22mm - 700C, 12x100 F/12x142 R
Tires
Maxxis Rambler 700c x 40mm TR Tan Wall EXO, Maxxis Rambler 700c x 40mm TR Tan Wall EXO
Brakes
Brakes
Shimano Dura Ace 9270 2-piston
Cockpit
Stem
Phoenix Team 31.8mm - 75mm(XS), 90mm(SM), 100mm(MD-XL)
Handlebar
Easton EC70 SL Carbon - 40cm (XS), 42cm (SM), 44cm (MD), 46cm (LG, XL)
Headset
Pivot Precision Sealed Integrated Cartridge
Seat
Saddle
Phoenix WTB Team Volt
Seatpost
Phoenix Pro ISO Flex Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.441 mm | 1.453 mm | 1.48 mm | 1.53 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 590 mm | 592 mm | 610 mm | 618 mm | 628 mm |
| Rake | 45 mm | 44 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 70 mm | 66 mm | 66 mm | 66 mm |
| Stack | 520 mm | 549 mm | 574 mm | 589 mm | 612 mm |
| Reach | 374 mm | 381 mm | 395 mm | 398 mm | 400 mm |
| Top Tube Length | 515 mm | 538 mm | 565 mm | 578 mm | 590 mm |
| Seat Tube Angle | 74.8 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 528 mm | 548 mm | 568 mm | 588 mm |
| Head Tube Angle | 70 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 155 mm | 170 mm | 195 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1000 mm | 1002 mm | 1020 mm | 1028 mm | 1038 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 705 mm | 766 mm | 787 mm | 805 mm | 825 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 161 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 164 cm | 174 cm | 182 cm | 189 cm | 200 cm |
