Polygon IMPRESSION AX DISC 2024
2024 Urban
Estimate price |
969$
Weight | 18 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
All Size
145cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminum
Suspension Fork
HI-TEN STEEL RIGID FORK
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO RD-M310 ALTUS
Shift Levers
SHIMANO ST-TX800-8R
Cassette
SHIMANO CS-HG31 ALTUS
Crank
PROWHEEL MAA543 42/34/24 x 170MM
Bottom Bracket
FP-B908N
Chain
KMC HV-408
Pedals
PLASTIC PEDAL
Wheels
Rims
ALLOY DOUBLE WALL RIMS W/ALLOY HUBS
Tires
PERFORMANCE TIRE 27.5"X2.10"
Brakes
Brakes
TEKTRO MD-300
Brake Levers
TEKTRO MD-300
Cockpit
Handlebar
ENTITY OE ALLOY WIDTH 680MM, RISE 40MM, BARBORE 31.8MM
Headset
FP-H863 ALLOY CAGED BEARING
Seat
Saddle
ENTITY SADDLE
Seatpost
ENTITY OE ALLOY SEATPOT 27.2mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | All Size |
|---|---|
| Stack Reach Ratio | 1.321 mm |
| Bottom Bracket Height | 300 mm |
| Stack | 555 mm |
| Reach | 420 mm |
| Top Tube Length | 590 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 430 mm |
| Head Tube Angle | 71 ° |
| Head Tube Length | 120 mm |
| Chainstay Length | 460 mm |
| Wheelbase | 1795 mm |
| Bottom Bracket Drop | 50 mm |
| Standover Height | 726 mm |
| Wheels | 650 |
| Rider Min Height | 145 cm |
| Rider Max Height | 185 cm |
