Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 60mm -
Groupset Tourney, Shimano -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL6 RIGID FRAME, 10X135MM, IS MOUNT
Suspension Fork
HSIN LUNG SUSPENSION FORK, TRAVEL 60MM
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO TOURNEY RD-TX800
Shift Levers
SHIMANO SL-RS45
Cassette
SHIMANO CS-HG200-8 12-32T
Crank
PROWHEEL A105PP 32T
Bottom Bracket
STEEL BB
Chain
KMC Z-8.3
Wheels
Rims
ALLOY DOUBLE WALL RIMS ALLOY HUBS
Tires
VEE XCV 24X2.10”
Brakes
Brakes
MECH D-BRAKE
Cockpit
Stem
ALLOY 40MM BARBORE: 25.4MM
Handlebar
STEEL 640MM BARBORE: 25.4MM
Seat
Saddle
POLYGON SADDLE STEEL RAIL
Seatpost
ALLOY 27.2X350MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.45 mm |
| Bottom Bracket Height | 300 mm |
| Front Center | 559 mm |
| Rake | 34 mm |
| Stack | 505 mm |
| Reach | 348 mm |
| Top Tube Length | 502 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 407 mm |
| Wheelbase | 966 mm |
| Bottom Bracket Drop | 15 mm |
| Standover Height | 573 mm |
| Wheels | 24" |
About this model
RELIC24 is part of the Polygon Relic24 model. Polygon released 5 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Youth bikes average price
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, you could also get a good Youth bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 419$. If we compare this with the average Youth bike cost we notice that the price is 50.72% more expensive.
RELIC24 components
Wheels size
As for the wheels, Polygon RELIC24 2020, has a 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The RELIC24 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
