Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 60mm -
Groupset Tourney, Shimano -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL6 RIGID FRAME, 10X135MM, IS MOUNT
Suspension Fork
HSIN LUNG SUSPENSION FORK, TRAVEL 60MM
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO TOURNEY RD-TX800
Shift Levers
SHIMANO SL-RS45
Cassette
SHIMANO CS-HG200-8 12-32T
Crank
PROWHEEL A105PP 32T
Bottom Bracket
STEEL BB
Chain
KMC Z-8.3
Wheels
Rims
ALLOY DOUBLE WALL RIMS ALLOY HUBS
Tires
VEE XCV 24X2.10”
Brakes
Brakes
MECH D-BRAKE
Cockpit
Stem
ALLOY 40MM BARBORE: 25.4MM
Handlebar
STEEL 640MM BARBORE: 25.4MM
Seat
Saddle
POLYGON SADDLE STEEL RAIL
Seatpost
ALLOY 27.2X350MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.45 mm |
| Bottom Bracket Height | 300 mm |
| Front Center | 559 mm |
| Rake | 34 mm |
| Stack | 505 mm |
| Reach | 348 mm |
| Top Tube Length | 502 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 407 mm |
| Wheelbase | 966 mm |
| Bottom Bracket Drop | 15 mm |
| Standover Height | 573 mm |
| Wheels | 24" |
About this model
RELIC24 belongs to the Polygon Relic24 model. 5 bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Youth bikes average price
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, you could also get a good Youth bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 449$. In conclusion, this bike price is 61.51% higher than the price of the average Youth bike.
RELIC24 components
Wheels
When it comes to wheels, the RELIC24 bike is equipped with the 24″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
