Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 60mm -
Groupset Tourney -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminum
Suspension Fork
SUSPENSION FORK 60mm TRAVEL
Drivetrain
Rear Derailleur
SHIMANO RD-TX800-SGS DIRECT ATTACH
Shift Levers
SHIMANO SL-RS45, 1x8 SPEED TRIGGER
Cassette
SHIMANO CS-HG200 12-32T
Crank
ALLOY 32T W/ SINGLE CHAIN GUARD, 152mm
Bottom Bracket
CARTIDGE BEARING 68x119mm
Chain
KMC Z-8.3
Pedals
PP PEDAL W/ REFLECTOR
Wheels
Front Hub
F: ALLOY QRx100mm 32H 6-BOLTS / R: ALLOY QRx135mm 32H 6-BOLTS
Rear Hub
F: ALLOY QRx100mm 32H 6-BOLTS / R: ALLOY QRx135mm 32H 6-BOLTS
Rims
507-20 32H FOR TYRE 507-28/62
Tires
VEE XCV 24"x2.10"
Brakes
Brakes
TEKTRO TS-325A
Brake Levers
TEKTRO TS-325A
Cockpit
Handlebar
STEEL HANDLEBAR, W: 640mm, BB: 25.4mm, R/D: 20mm, B: 6degree
Headset
ZERO STACK (ZS) CARTRIDGE BEARING FOR NORMAL HEAD TUBE, ZS 44/28.6 | ZS 44/30
Seat
Saddle
POLYGON SADDLE
Seatpost
ALLOY SEATPOST
