Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Shimano GRX 600 Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 164cm
MD
162cm - 176cm
LG
174cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
carbon
Suspension Fork
CARBON RIGID
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX810
Shift Levers
SHIMANO GRX ST-RX600, 2x11-SPEED BRIFTER
Cassette
SHIMANO CS-HG700, 11-34T
Crank
PRAXIS ALBA GR M30, 48-32T
Bottom Bracket
PRAXIS ALBA T47 M30, 85.5mm
Chain
KMC X11
Wheels
Front Hub
F: NOVATEC D791SB 12x100mm 32H CL / R: NOVATEC D792SB 12x142mm 32H CL FOR SPROCKET
Rear Hub
F: NOVATEC D791SB 12x100mm 32H CL / R: NOVATEC D792SB 12x142mm 32H CL FOR SPROCKET
Rims
F: ALLOY DOUBLE WALL FV H: 20 622 32H TLR / R: ALLOY DOUBLE WALL FV H: 20 622 32H TLR
Spokes
F: STAINLESS 14G NDS:290 & DS:292 W/ NIPPLE BRASS / R: STAINLESS 14G NDS:292 & DS290: W/ NIPPLE BRASS
Tires
MAXXIS RE-FUSE 700X32C
Brakes
Brakes
SHIMANO GRX HYDRAULIC DISC
Brake Levers
SHIMANO ST-RX600
Cockpit
Handlebar
POLYGON EXPERT, W: 420mm (S, M) / 440mm (L, XL), BB: 31.8mm, R/D: 125mm, B/R: 77mm
Headset
TOKEN TK155SP-36 W/ SEALED BEARING, IS 52/28.6 | IS 52/40
Seat
Saddle
FIZIK TERRA ARGO X7
Seatpost
CARBON, DxL: 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.526 mm | 1.543 mm | 1.553 mm | 1.561 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 595 mm | 601 mm | 624 mm | 645 mm |
| Rake | 41 mm | 42 mm | 41 mm | 41 mm |
| Trail | 82 mm | 71 mm | 70 mm | 69 mm |
| Stack | 566 mm | 591 mm | 621 mm | 648 mm |
| Reach | 371 mm | 383 mm | 400 mm | 415 mm |
| Top Tube Length | 526 mm | 550 mm | 581 mm | 610 mm |
| Seat Tube Angle | 74.75 ° | 74.26 ° | 73.76 ° | 73.26 ° |
| Seat Tube Length | 404 mm | 448 mm | 492 mm | 535 mm |
| Head Tube Angle | 70.25 ° | 71.77 ° | 72.06 ° | 72.26 ° |
| Head Tube Length | 143 mm | 163 mm | 193 mm | 221 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 997 mm | 1003 mm | 1026 mm | 1048 mm |
| Bottom Bracket Drop | 79 mm | 79 mm | 79 mm | 79 mm |
| Standover Height | 701 mm | 741 mm | 783 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 162 cm | 174 cm | 187 cm |
| Rider Max Height | 164 cm | 176 cm | 189 cm | 195 cm |
