principia 10 2023
2023 Road
Estimate price |
1,279$
Weight | 11.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Aluminium
Drivetrain
Rear Derailleur
Shimano Claris R2000
Front Derailleur
Shimano Claris R2000
Shift Levers
Shimano Claris SL-R2000 2x8
Cassette
Sunrace CSM55 8sp 11-32T
Crank
Shimano FC-RS200 50/34T 170mm
Chain
KMC X8, 114 links
Pedals
Not included
Wheels
Rims
28in (700)
Tires
Panaracer GravelKing SK 38-622
Brakes
Brakes
Front: Tektro MD-C400 mechanical disc brake, 160 mm. rotor, Rear: Tektro MD-C400 mechanical disc brake, 160 mm. rotor
Cockpit
Stem
Kalloy AS-DC1, 31.8 mm.
Handlebar
Kalloy HBL002, 31.8 mm.
Seat
Saddle
Foming DDK-510
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm | 61cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.47 mm | 1.46 mm | 1.58 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 639 mm | 638 mm | 638 mm | 649 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73.82 mm | 67.29 mm | 64.05 mm | 54.42 mm |
| Stack | 564.67 mm | 587.61 mm | 589.63 mm | 652.81 mm |
| Reach | 399.13 mm | 400.76 mm | 405.2 mm | 412.68 mm |
| Top Tube Length | 556 mm | 564 mm | 569 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 610 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 73 ° |
| Head Tube Length | 135 mm | 155 mm | 155 mm | 155 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1064 mm | 1064 mm | 1063 mm | 1075 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 716 mm | 761 mm | 799 mm | 860 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
10 completes the Principia 10 model. Principia launched 1 bike of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 1167$. Comparing this to the average Gravel bike price, we see that the price is 110.97% smaller.
Average weight for Gravel bikes
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
much heavier than average, 10 has a weight of 11.8 kg (26.01 lbs). In conclusion, the average Gravel bike weighs 45.14% less than 10.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Principia 10 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
