Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
Principia CHK11 Monocoque Full Carbon
Drivetrain
Rear Derailleur
Shimano GRX RX820
Front Derailleur
Shimano GRX RX820
Cassette
Shimano CS-HG710 12sp 11-36T
Crank
Shimano GRX RX610 46-30T 170mm
Chain
Shimano CN-M6100, 118L
Pedals
Not included
Wheels
Rims
Gravel double butted aluminium
Tires
Panaracer GravelKing SK 700x43C black/brown
Brakes
Brakes
Front: Shimano GRX RX820 hydraulic disc brake, 160 mm. rotor, Rear: Shimano GRX RX820 hydraulic disc brake, 160 mm. rotor
Cockpit
Stem
FSA ST-OS-185 NS SMR alloy 31,8x90mm -6°
Handlebar
FSA A-Wing Pro, 31,8mm/440mm
Seat
Saddle
Foming DDK-510
Seatpost
Kalloy SP-369, aluminium, 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.573 mm | 1.575 mm | 1.572 mm | 1.585 mm |
| Bottom Bracket Height | 500 mm | mm | mm | mm |
| Front Center | 595 mm | 607 mm | 622 mm | 639 mm |
| Trail | 72.8 mm | 69.4 mm | 69.4 mm | 69.4 mm |
| Stack | 581.5 mm | 597.7 mm | 609.4 mm | 628.3 mm |
| Reach | 369.6 mm | 379.4 mm | 387.6 mm | 396.5 mm |
| Seat Tube Angle | 73.2 ° | 73.2 ° | 72.9 ° | 72.9 ° |
| Seat Tube Length | 82.5 mm | 82.5 mm | 80 mm | 80 mm |
| Head Tube Length | 545 mm | 560 mm | 575 mm | 590 mm |
| Wheelbase | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheels | 700 | 700 | 700 | 700 |
