principia G6 2023
2023 Road
Estimate price |
4,472$
Weight | 9.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Principia CHF-18 Carbon
Suspension Fork
Principia CHK80-ET-M12 Carbon
Drivetrain
Rear Derailleur
SRAM Rival XPLR eTap AXS Max 44T
Shift Levers
SRAM Rival eTap AXS 1x12
Cassette
SRAM Rival XPLR XG-1251 12sp 10-44T
Crank
SRAM Rival 1 Dub Wide 44T
Chain
SRAM Rival, 120 links
Pedals
Not included
Wheels
Rims
LiTE Gravel w. thru axle, tubeless ready
Tires
Panaracer GravelKing SK 700x38C
Brakes
Brakes
Front: SRAM Rival AXS hydraulic disc brake, 160 mm. rotor, Rear: SRAM Rival AXS hydraulic disc brake, 160 mm. rotor
Cockpit
Stem
Ritchey
Handlebar
Ritchey Comp VentureMax, 31.8 mm/440 mm
Grips
Principia bar tape
Seat
Saddle
Ritchey Comp Streem
Seatpost
Ritchey
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.58 mm | 1.58 mm | 1.58 mm | 1.59 mm |
| Bottom Bracket Height | 275 mm | 277.5 mm | 277.5 mm | 280 mm | 280 mm |
| Front Center | 597 mm | 602 mm | 613 mm | 625 mm | 640 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74.4 mm | 72.8 mm | 69.4 mm | 69.4 mm | 69.4 mm |
| Stack | 559.1 mm | 576.5 mm | 592.7 mm | 604.4 mm | 623.3 mm |
| Reach | 363.6 mm | 364.6 mm | 374.4 mm | 382.6 mm | 391.5 mm |
| Top Tube Length | 520 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 73.2 ° | 73.2 ° | 72.9 ° | 72.9 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 70.75 ° | 71.25 ° | 71.25 ° | 71.25 ° |
| Head Tube Length | 115 mm | 135 mm | 150 mm | 165 mm | 185 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1012 mm | 1018 mm | 1029 mm | 1042 mm | 1058 mm |
| Bottom Bracket Drop | 85 mm | 82 mm | 82 mm | 80 mm | 80 mm |
| Standover Height | 739 mm | 756 mm | 773 mm | 791 mm | 809 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
G6 completes the Principia G6 model. 1 bike variation carries this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2023 and its price was 4140$. Comparing this to the average Gravel bike price, we see that the price is 68.16% higher.
Gravel bikes average weight
Gravel bikes weigh an average of 8.45 kg (18.63 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
G6 weighs 9.3 kg (20.5 lbs) and is considerably heavier than the average. To sum up, it’s 10.06% heavier than the average weight of Gravel bikes.
G6 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The G6 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
