Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Gates -
Suspension Rigid -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Butted Ultralight 6061 T6 Aluminum
Suspension Fork
Full Carbon 1-1/2" Tapered
Drivetrain
Shift Levers
Integrated into Right Brake, 11-Speed
Crank
Gates S300 or 174HUDSON External Bearing BB
Wheels
Front Hub
12mm Thru Axle, Sealed Cartridge Bearings
Rear Hub
Shimano Alfine 11
Rims
WTB i23 ST Tubeless Ready (Apollo) / WTB KOM Team (Apollo Ti)
Tires
Tubeless Ready Goodyear Connector Ultimate 40mm or WTB Byway Tires 700x40mm (Apollo Ti)
Brakes
Brakes
174HUDSON Semi-Hydraulic Disc Brakes
Cockpit
Stem
Alloy, 90mm (S/M), 100mm (L/XL)
Headset
Integrated Sealed Cartridge Bearings
Seat
Saddle
WTB Volt
Seatpost
Carbon Fiber
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Top Tube Length | 550 mm | 560 mm | 575 mm | 595 mm |
| Seat Tube Length | 445 mm | 495 mm | 555 mm | 600 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 71.5 ° |
| Head Tube Length | 105 mm | 140 mm | 170 mm | 190 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1040 mm | 1042 mm | 1053 mm | 1065 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
